CY7C68013A-56LTXC Electronic Components

CY7C68013A-56LTXC Electronic Components belongs to EZ-USB® FX2LP™ USB Microcontroller and High-Speed USB Peripheral Controller.CY7C68013A is identical to CY7C68014A in form, fit, and functionality. CY7C68015A is identical to CY7C68016A in form, fit, and functionality. CY7C68014A and CY7C68016A have a lower suspend current than CY7C68013A and CY7C68015A respectively and are ideal for power-sensitive battery applications.

USB Signaling Speed FX2LP operates at two of the three rates defined in the USB Specification Revision 2.0, dated April 27, 2000:
-Full speed, with a signaling bit rate of 12 Mbps
-High speed, with a signaling bit rate of 480 Mbps FX2LP does not support the Low Speed signaling mode of 1.5 Mbps

Product Applications

Portable video recorder
MPEG/TV conversion
DSL modems
ATA interface
Memory card readers
Legacy conversion devices
Cameras
Scanners
Wireless LAN
MP3 players
Networking

Product Features

USB 2.0 USB IF Hi-Speed certified (TID # 40460272)
Single-chip integrated USB 2.0 transceiver, smart SIE, and enhanced 8051 microprocessor
Available in commercial and industrial temperature grades (all packages except VFBGA)
Separate data buffers for the setup and data portions of a CONTROL transfer
3.3-V operation with 5-V tolerant inputs
Additional programmable (BULK/INTERRUPT) 64-byte endpoint
