LM5008MMX/NOPB Electronic Components

Kinglionski is LM5008MMX/NOPB Electronic Components Electronic Components suppliers in China who can wholesale LM5008MMX/NOPB.The LM5008MMX/NOPB 350-mA step-down switching converter features all of the functions needed to implement a low-cost and efficient buck regulator.

This high-voltage converter has an integrated 100-V N-channel buck switch and operates over an input voltage range of 9 V to 95 V. The device is easy to implement and is provided in the 8-pin VSSOP and the thermally enhanced 8-pin WSON packages.

The converter uses a hysteretic control scheme with a PWM on-time inversely proportional to VIN. This feature allows the operating frequency to remain relatively constant.

The hysteretic control requires no loop compensation. An intelligent current limit is implemented with forced off-time, which is inversely proportional to VOUT.

This scheme ensures short-circuit protection while providing minimum foldback. Other protection features include: thermal shutdown, VCC undervoltage lockout, gate drive undervoltage lockout, and maximum duty cycle limiter.

LM5008MMX/NOPB Electronic Components Parameter (Specification)

Operating Input Voltage Range: 6 V to 95 V
Integrated 100-V, N-Channel Buck Switch
Internal VCC Regulator
No Loop Compensation Required
Ultra-Fast Transient Response
On-Time Varies Inversely With Line Voltage

Operating Frequency Remains Constant With Varying Line Voltage and Load Current
Adjustable Output Voltage
Highly Efficient Operation
Precision Internal Reference
Low Bias Current
Intelligent Current Limit Protection
Thermal Shutdown
8-Pin VSSOP and WSON Packages

LM5008MMX/NOPB Electronic Components Feature And Application

Non-Isolated Telecommunication Buck Regulators
Secondary High-Voltage Post Regulators

48-V Automotive Systems
