STM32F100R8T6BTR Electronics

STM32F100R8T6BTR Electronics belongs to mainstream Value line, Arm Cortex-M3 MCU with 64 Kbytes of Flash memory, 24 MHz CPU, motor control and CEC functions. The STM32F100R8T6BTR microcontrollers incorporate the high-performance ARM® Cortex®-M3 32-bit RISC core operating at a 24 MHz frequency, high-speed embedded memories (Flash memory up to 128 Kbytes and SRAM up to 8 Kbytes), and an extensive range of enhanced peripherals and I/Os connected to two APB buses.

All devices offer standard communication interfaces (up to two I2Cs, two SPIs, one HDMI CEC, and up to three USARTs), one 12-bit ADC, two 12-bit DACs, up to six general-purpose 16-bit timers and an advanced-control PWM timer.

Product Features

Type	Main product features
STM32F100R8T6BTR	Core: ARM® 32-bit Cortex®-M3 CPU –24 MHz maximum frequency, 1.25 DMIPS/MHz (Dhrystone 2.1) performance –Single-cycle multiplication and hardware division
	Memories –16 to 128 Kbytes of Flash memory –4 to 8 Kbytes of SRAM
	Low power –Sleep, Stop and Standby modes –VBAT supply for RTC and backup registers

Product Description

The STM32F100R8T6BTR low- and medium-density devices operate in the – 40 to + 85 °C and – 40 to + 105 °C temperature ranges, from a 2.0 to 3.6 V power supply. A comprehensive set of power-saving mode allows the design of low-power applications. These microcontrollers include devices in three different packages ranging from 48 pins to 100 pins. Depending on the device chosen, different sets of peripherals are included.

These features make these microcontrollers suitable for a wide range of applications such as application control and user interfaces, medical and hand-held equipment, PC and gaming peripherals, GPS platforms, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVACs.
