VN330SPTR-E Electronics

VN330SPTR-E Electronics belongs to Quad high side smart power solid state relay.

Product Features

Type	Main product features
VN330SPTR-E	Output current: 0.7 A per channel
	Digital I/O clamped at 32 V minimum voltage
	Shorted load and overtemperature protections
	Built-in current limiter
	Undervoltage shutdown
	Open drain diagnostic output
	Fast demagnetization of inductive loads
	Conforms to IEC 61131-2

Product Description

The VN330SP-E is a monolithic device developed using the VIPower technology, intended to drive four independent resistive or inductive loads with one side connected to ground. Active current limitation prevents dropping of the system power supply in case of shorted load. Built-in thermal shutdown protects the chip from overtemperature and short-circuit. The open drain diagnostic output indicates overtemperature conditions.
