VN340SPTR-E Electronics

VN340SPTR-E Electronics belongs to Quad high side smart power solid state relay.

Product Features

Type	Main product features
VN340SPTR-E	Output current: 0.7 A per channel
	Digital I/O clamped at 32 V minimum voltage
	Shorted load and overtemperature protections

Product Description

The VN340SP-E is a monolithic device developed using ST VIPower™ technology, intended to drive four independent resistive or inductive loads with one side connected to ground. Active current limitation avoids dropping the system power supply in case of shorted load. Built-in thermal shutdown protects the chip from overtemperature and short-circuit. The open drain diagnostic output indicates overtemperature conditions. Each I/O is pulled down when the overtemperature condition of the relative channel is verified.

Product Package

In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK® packages, depending on their level of environmental compliance. ECOPACK® specifications, grade definitions and product status are available at: www.st.com. ECOPACK® is an ST trademark.
