VN5016AJ-E Electronics

Kinglionski is the agent and distributor of STMicroelectronics model VN5016AJ-E Electronics, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

VN5016AJ-E Electronics belongs to Single channel high side driver with analog current sense for automotive applications.

Product Features

Type	Main product features
VN5016AJ-E	Main features –Inrush current active management by power limitation –Very low stand-by current
	Diagnostic functions –Proportional load current sense –High current sense precision for wide range currents
	Protection –Undervoltage shut-down –Overvoltage clamp

Product Description

The VN5016AJ-E is a monolithic device made using STMicroelectronics VIPower M0-5 technology. It is intended for driving resistive or inductive loads with one side connected to ground. Active VCC pin voltage clamp protects the device against low energy spikes (see ISO7637 transient compatibility table). This device integrates an analog current sense which delivers a current proportional to the load current (according to a known ratio) when CS_DIS is driven low or left open.

When CS_DIS is driven high, the CURRENT SENSE pin is in a high impedance condition.

Output current limitation protects the device in overload condition. In case of long overload duration, the device limits the dissipated power to safe level up to thermal shut-down intervention. Thermal shut-down with automatic restart allows the device to recover normal operation as soon as fault condition disappears.
