AD8131ARZ-REEL7 Devices Electronic

Kinglionski is the agent and distributor of Analog Devices electronic model AD8131ARZ-REEL7 Devices Electronic, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The AD8131ARZ-REEL7 Devices Electronic is a differential or single-ended input to differential output driver requiring no external components for a fixed gain of 2. The AD8131ARZ-REEL7 is a major advancement over op amps for driving signals over long lines or for driving differential input ADCs. The AD8131ARZ-REEL7 has a unique internal feedback feature that provides output gain and phase matching that are balanced to −60 dB at 10 MHz, reducing radiated EMI and suppressing harmonics.

The AD8131ARZ-REEL7 can replace transformers in a variety of applications, preserving low frequency and dc information. The AD8131ARZ-REEL7 does not have the susceptibility to magnetic interference and hysteresis of transformers. It is smaller, easier to work with, and has the high reliability associated with ICs.

Product Features

Type	Main product features
AD8131ARZ-REEL7	High speed： -400 MHz, −3 dB full power bandwidth -2000 V/μs slew rate
	Fixed gain of 2 with no external components
	Internal common-mode feedback to improve gain and phase balance: −60 dB @ 10 MHz
	Separate input to set the common-mode output voltage
