ADCLK854BCPZ-REEL7 Devices Electronic

The ADCLK854BCPZ-REEL7 Devices Electronic is a 1.2 GHz/250 MHz LVDS/CMOS fanout buffer optimized for low jitter and low power operation. Possible configurations range from 12 LVDS to 24 CMOS outputs, including combinations of LVDS and CMOS outputs. Three control lines are used to determine whether fixed blocks of outputs (three banks of four) are LVDS or CMOS outputs.

The ADCLK854BCPZ-REEL7 offers two selectable inputs and a sleep mode feature. The IN_SEL pin state determines which input is fanned out to all the outputs. The SLEEP pin enables a sleep mode to power down the device.

Product Features

Product Applications

Low jitter clock distribution

Clock and data signal restoration

Level translation

Wireless communications

Wired communications

Medical and industrial imaging

ATE and high performance instrumentation
