ATA6560-GAQW-N Devices Electronic

ATA6560-GAQW-N Devices Electronic Features

-Fully ISO 11898-2, ISO 11898-5, and SAE J2284 Compliant

-CANFDReady

-CommunicationSpeedupto5Mbps

-LowElectromagneticEmission(EME)andHigh

-Electromagnetic Immunity (EMI)

-DifferentialReceiverwithWideCommon-Mode Range

-ATA6560:SilentMode(ReceiveOnly)

-RemoteWake-UpCapabilityviaCANBus

-FunctionalBehaviorPredictableunderAllSupply Conditions

-TransceiverDisengagesfromtheBuswhenNot Powered Up

-RXDRecessiveClampingDetection

-HighElectrostaticDischarge(ESD)Handling

-Capability on the Bus Pins

-BusPinsProtectedAgainstTransientsin

-Automotive Environments

-TransmitData(TXD)DominantTime-Out Function

-UndervoltageDetectiononVCCandVIOPins

-CANH/CANLShort-CircuitandOvertemperature Protected

-QualifiedAccordingtoAEC-Q100:Only ATA6560-GAQW, ATA6560-GBQW, ATA6561-GAQW, and ATA6561-GBQW

-Packages:SOIC8,VDFN8withWettableFlanks (Moisture Sensitivity Level 1)

Product Applications

Classical CAN and CAN FD networks in the following applications:

Automotive

Industrial

Aerospace

Medical

Consumer

Product Description

The ATA6560/1 is a high-speed CAN transceiver that provides an interface between a Controller Area Net- work (CAN) protocol controller and the physical two-wire CAN bus. The transceiver is designed for high-speed (up to 5 Mbps) CAN applications in the automotive industry, providing differential transmit and receive capability to (a microcontroller with) a CAN protocol controller.

It offers improved Electromagnetic Compatibility (EMC) and ESD performance, as well as features such as:

- IdealpassivebehaviortotheCANbuswhenthe supply voltage is off

-Directinterfacingtomicrocontrollerswithsupply voltages from 3V to 5V (ATA6561)

Three operating modes, together with the dedicated fail-safe features, make the ATA6560/1 an excellent choice for all types of high-speed CAN networks, especially in nodes requiring a Low-Power mode with wake-up capability via the CAN bus.
