ATMEGA88V-10AU Devices Electronic

Product Introduction

Wholesale hot sale ATMEGA88V-10AU Devices Electronic with low price.  The Atmel® ATmega48/V/ 88/V /168/V is a low-power CMOS 8-bit microcontroller based on the AVR® enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega48/V/ 88/V /168/V achieves throughputs close to 1MIPS per MHz. This empowers system designer to optimize the device for power consumption versus processing speed.

Product Feature

High Performance, Low Power Atmel®AVR® 8-Bit Microcontroller Family -Advanced RISC Architecture

-High Endurance Non-volatile Memory Segments

-Atmel® QTouch® Library Support

Peripheral Features

– Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode

– Six PWM Channels

– 8-channel 10-bit ADC in TQFP and QFN/MLF package

Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection

– Internal Calibrated Oscillator

– External and Internal Interrupt Sources

I/O and Packages

– 23 Programmable I/O Lines

– 28-pin PDIP, 32-lead TQFP, 28-pad QFN/MLF and 32-pad QFN/MLF  Operating Voltage:

– 2.7 - 5.5V for ATmega48/88/168

– 1.8 - 5.5V for ATmega48V/88V/168V

Temperature Range: – -40°C to 85°C

Speed Grade:

– ATmega48/88/168: 0 - 10MHz @ 2.7V - 5.5V, 0 - 20MHz @ 4.5V - 5.5V

– ATmega48V/88V/168V: 0 - 4MHz @ 1.8V - 5.5V, 0 - 10MHz @ 2.7V - 5.5V Power Consumption at 1MHz, 1.8V, 25°C

Product Description

The Atmel AVR® core combines a rich instruction set with 32 general purpose working registers. All the 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in a single instruction executed in one clock cycle. The resulting architecture is more code efficient while achieving throughputs up to ten times faster than conventional CISC microcontrollers.

The ATmega48/V/ 88/V /168/V is supported with a full suite of program and system development tools including: C Compilers, Macro Assemblers, Program Debugger/Simulators, In-Circuit Emulators, and Evaluation kits.
