BQ76PL455ATPFCRQ1 Electronic Components

Kinglionski is the agent and distributor of Texas Instruments model BQ76PL455ATPFCRQ1 Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The BQ76PL455ATPFCRQ1 Electronic Components is an integrated 16-cell monitor, protector, and cell balancer designed for high-reliability automotive applications with many built-in self-diagnostic features.Up to 16 BQ76PL455ATPFCRQ1 devices can be connected in series using the high-speed differential communications interface, which has been evaluated for compliance with Bulk Current Injection (BCI) standards.

This capacitorisolated communications link provides effective common-mode noise rejection. The BQ76PL455ATPFCRQ1 communicates with the host through a high-speed UART interface. The BQ76PL455ATPFCRQ1 provides up to six general-purpose, programmable, digital I/O ports, as well as eight AUX ADC inputs, typically used to monitor externally supplied temperature sensors. Configuration of the digital I/O ports can be set to generate faults based on conditions set in register GP_FLT_IN. Further configuration of these faults can be for an indication of a fault on the FAULT_N output pin.

The BQ76PL455ATPFCRQ1 device is an integrated 16-cell battery monitoring and protection device, designed for high-reliability automotive applications. The integrated high-speed, differential, capacitor-isolated communications interface allows up to sixteen BQ76PL455ATPFCRQ1 devices to communicate with a host via a single high-speed Universal Asynchronous Receiver/Transmitter (UART) interface.

Product Features

Type	Main product features
BQ76PL455ATPFCRQ1	Monitors and Balances 6-to-16 Cells per Device
	Highly Accurate Monitoring
	Engineered for High System Robustness
