DRV8305NQPHPRQ1 Electronic Components

Kinglionski is the agent and distributor of Texas Instruments model DRV8305NQPHPRQ1 Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The DRV8305NQPHPRQ1 Electronic Components is a 4.4-V to 45-V automotive gate driver IC for three-phase motor driver applications. This device reduces external component count in the system by integrating three half-bridge drivers, charge pump, three current shunt amplifiers, an uncommited 3.3-V or 5-V, 50-mA LDO, and a variety of protection circuits.

The DRV8305-Q1 provides overcurrent, shoot-through, overtemperature, overvoltage, and undervoltage protection. Fault conditions are indicated by the nFAULT pin and specific fault information can be read back from the SPI registers. The protection circuits are highly configurable to allow adaptation to different applications and support limp home operation.DRV8305NQPHPRQ1 belongs to Automotive 12-V battery 3-phase smart gate driver of Texas Instruments.

The DRV8305-Q1 device is a gate driver IC for threephase motor-drive applications. The device provides three high-accuracy half-bridge drivers, each capable of driving a high-side and low-side N-channel MOSFET. A charge pump driver supports 100% duty cycle and low-voltage operation for cold crank situations. The device can tolerate load dump voltages up to 45-V.

Product Features

Type	Main product features
DRV8305NQPHPRQ1	AEC-Q100 qualified for automotive applications
	4.4-V to 45-V operating voltage
	1.25-A and 1-A Peak gate drive currents
	Programmable high- and low-side slew-rate control
