LMR36506MSC5RPERQ1 Texas Instrument Electronic Components

Factory Directly Supply Quality LMR36506MSC5RPERQ1 Texas Instrument Electronic Components made in China. The TPS2H160-Q1 device is a smart high-side switch, with internal charge pump and dual-channel integrated NMOS power FETs. For version A, the device implements the digital fault report with an open-drain structure.

For version B, high-accuracy current sense makes the diagnostics more accurate without further calibration.

The external high-accuracy current limit allows setting the current-limit value by applications. For inductive loads (relays, solenoids, valves), the device implements an active clamp between drain and source to protect itself. The TPS2H160-Q1 device is a smart high-side switch for a wide variety of resistive, inductive, and capacitive loads, including low-wattage bulbs, LEDs, relays, solenoids, heaters, and sub-modules

The TPS2H160-Q1 family is a fully-protected dualchannel smart high-side switch, with integrated 160- mΩ NMOS power FETs. Full diagnostics and high-accuracy current-sense features enable intelligent control of the load. An external adjustable current limit improves reliability of the whole system by limiting the inrush or overload current.

Product Features

Type	Main productFeatures
LMR36506MSC5RPERQ1	Qualified for Automotive Applications
	AEC-Q100 Qualified With the Following Results
	Functional safety capable
	Dual-Channel 160-mΩSmart High-Side Switch With Full Diagnostics

Product Feature And Application

Dual-Channel LED Drivers, Bulb Drivers
Dual-Channel High-Side Switches for Sub-Modules
Dual-Channel High-Side Relay, Solenoid Drivers
