MKL13Z64VLK4 Electronic Components

Product Introduction

The MKL13Z64VLK4 Electronic Components is optimized for cost-sensitive and batterypowered applications requiring low-power general purpose connectivity. The product offers:

①Embedded ROM with boot loader for flexible program upgrade

②High accuracy internal voltage and clock reference

③FlexIO to support any standard and customized serial peripheral emulation

④Hardware CRC module

⑤Down to 60uA/MHz in very low power run mode and 1.83uA in deep sleep mode (RAM + RTC retained)

Product System

①4-channel asynchronous DMA controller

②Watchdog

③Low-leakage wakeup unit

④Two-pin Serial Wire Debug (SWD) programming and debug interface

⑤Micro Trace Buffer

⑥Bit manipulation engine

⑦Interrupt controller

Product Peripherals

①One UART module supporting ISO7816, operating up to 1.5 Mbit/s

②Two low-power UART modules supporting asynchronous operation in

③low-power modes

④Two I2C modules and I2C0 supporting up to 1 Mbit/s

⑤Two 16-bit SPI modules supporting up to 24 Mbit/s

⑥One FlexIO module supporting emulation of additional UART, IrDA, SPI, I2C, PWM and other serial modules, etc.

⑦One 16-bit 818 ksps ADC module with high accuracy internal voltage reference (Vref) and up to 20 channels

⑧High-speed analog comparator containing a 6-bit DAC for programmable reference input

⑨One 12-bit DAC

⑩1.2 V internal voltage reference

Product Packages

①80 LQFP 12mm x 12mm, 0.5mm pitch, 1.6mm thickness

②64 LQFP 10mm x 10mm, 0.5mm pitch, 1.6mm thickness

③64 MAPBGA 5mm x 5mm, 0.5mm pitch, 1.23mm thickness (Package Your Way)

④48 QFN 7mm x 7mm, 0.5mm pitch, 0.65mm thickness (Package Your Way)

⑤32 QFN 5mm x 5mm, 0.5mm pitch, 0.65mm thickness (Package Your Way)
