S6J336CHTBSC20000 Infineon Electronic Components

S6J336CHTBSC20000 is a series of Automotive Cluster applications in general meter control to connect to the driver as speed meter, tachometer, temperature meter, and fuel meter. This embedded device enables next-generation functions such as Controller Area Network with Flexible Data rate (CAN FD) and Secure Hardware Extension (SHE). MCUs for this application require an operating temperature range of TA -40 °C to 105 °C and Automotive Electronics Council (AEC) qualification.

Any semiconductor devices have inherently a certain rate of failure. You must protect against injury, damage or loss from such failures by incorporating safety design measures into your facility and equipment such as redundancy, fire protection, and prevention of overcurrent levels and other abnormal operating conditions.

S6J336CHTBSC20000 Infineon Electronic Components Features

32-bit Arm® Cortex®-R5F CPU core at up to 132 MHz
80-MHz internal flash memory access speed
Flash memory size (max)
-TC-Flash: 2,112 KB/ Work-Flash: 112 KB
RAM size (max)
-TC-RAM: 128 KB/ System -RAM: 128 KB (this includes 16 KB + 8 KB back-up area)

5 V or 3.3 V power supply voltage

Packages

-LQFP packages (144-pin)
-TEQFP packages (176-pin/144-pin)
ASIL-B support for ISO 26262 specification
CMOS 40-nm technology
JTAG debug interface
Operating temperature: -40 to 105 °C
