SAK-TC387QP-160F300S Infineon Electronic Components

SAK-TC387QP-160F300S  belongs to 32-Bit Single-Chip Microcontroller of infineon electronic components.

The rate at which current is drawn from the external regulator (dIEXT /dt, dIDD /dt or dIDDP3 /dt) is limited in the Start-up phase to a maximum of 100 mA with 100 us settling time. PORST is active/asserted when either PORST (input) or PORST (output) is active/asserted.

PORST (input) active means that the reset is held active by external agents by pulling the PORST pin low. It is recommended to keep the PORST (input) asserted until all the external supplies are above their primary reset thresholds.

PORST (output) active means that µC asserts the reset internally and drives the PORST pin low thus propagating the reset to external devices.

The PORST (output) is asserted by the µC when at least one among the three supply domains (VDD, VDDP3 or VEXT) violate their primary under-voltage reset thresholds.The PORST (output) is de-asserted by the µC when all supplies are above their primary reset thresholds and the basic supply and clock infrastructure is available. During reset release at T3, the load jump of upto 150 mA (dIDD) is expected.

SAK-TC387QP-160F300S Infineon Electronic Components Features

High Performance Microcontroller with four CPU cores
Four 32-bit super-scalar TriCore CPUs (TC1.6.2P), each having the following features:
– Superior real-time performance
– Strong bit handling
– Fully integrated DSP capabilities

– Multiply-accumulate unit able to sustain 2 MAC operations per cycle

Lockstepped shadow cores for two TC1.6.2P
Multiple on-chip memories
– All embedded NVM and SRAM are ECC protected
– up to 10 Mbyte Program Flash Memory (PFLASH)
– up to 512 Kbyte Data Flash Memory (DFLASH 0) usable for EEPROM emulation
– 128 Kbyte Memory (LMU)
– BootROM (BROM)
