TL4242TDRJRQ1 Texas Instrument Electronic Components

Kinglionski is the agent and distributor of TL4242TDRJRQ1 Texas Instrument Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The TL4242TDRJRQ1 device is an integrated adjustable constant-current source, driving loads up to 500 mA. One can adjust the output current level through an external resistor. The device design is for supplying high-power LEDs (for example, OSRAM Dragon LA W57B) under the severe conditions of automotive applications, resulting in constant brightness and extended LED lifetime.

The integrated PWM input of the TL4242TDRJRQ1 device permits LED brightness regulation by pulse-width modulation (PWM). The high-input impedance of the PWM input allows operating the LED driver as a protected high-side switch.

Product Features

Type	Main product features
TL4242TDRJRQ1	Qualified for Automotive Applications
	AEC-Q100 Test Guidance With the Following Results
	Adjustable Constant Current up to 500 mA
	Wide Input-Voltage Range up to 42 V
