TPS61021ADSGR Electronic Components

Kinglionski is the agent and distributor of Texas Instruments model TPS61021ADSGR Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The TPS61021ADSGR Electronic Components synchronous step-up converter is designed to operate from an input voltage supply range between 0.5 V and 4.4 V with 3-A valley switch current limit. The TPS61021ADSGR typically operates at a quasiconstant frequency pulse width modulation (PWM) at moderate to heavy load currents. The switching frequency is 2 MHz when the input voltage is above 1.5 V.

The switching frequency reduces down to 1 MHz when the input voltage goes down from 1.5 V to 1 V. At light load currents, the TPS61021A converter operates in power-save mode with pulse frequency modulation (PFM). During PWM operation, the converter uses adaptive constant ontime valley current mode control scheme to achieve excellent line/load regulation and allows the use of a small inductor and ceramic capacitors. Internal loop compensation simplifies the design process while minimizing the number of external components.

Product Features

The TPS61021ADSGR provides a power supply solution for portable or smart devices powered by alkaline, NiMH, Li-Mn, or Li-ion batteries. The TPS61021ADSGR is capable of outputting 3.3-V voltage and 1.5-A current from a battery discharged to as low as 1.8 V. Capable of operating with 0.5-V input voltage enables the TPS61021ADSGR to extend the battery run time.

Product Applications

Type	Main product features
TPS61021ADSGR	Input Voltage Range: 0.5 V to 4.4 V
	0.9 V Minimum Input Voltage for Startup
	2.0-MHz Switching Frequency
	Input Voltage Range: 0.5 V to 4.4 V
