111 9FGP204BKLF Electronic Components

The 111 9FGP204BKLF Electronic Components is a peripheral clock for Intel Servers. It is driven with a 25MHz crystal and generates a variety of clocks, including 125MHz RGMII. An SMBus interface allows full control of the device.

Output Features:

1 - 0.7V current-mode differential CPU pair
6 - 50MHz RMII outputs
2 - 125MHz RGMII outputs
1 - DOT 96MHz output
1 - 33.33MHz output
1 - 32.768KHz output
2 - 25MHz REF outputs

Key Specifications:

Exact synthesis on CPU, RGMII, RMII & 33.33MHz clocks
+/- 100ppm frequency accuracy on other clocks

Product Application

Peripheral Clock for Intel Server

Product Features

Selectable SMBus Address - D0/D1 or C0/C1
Spread Spectrum capability on CPU and DOT 96MHz clocks
SMBus Control:
- M/N and spread programming on CPU and DOT 96MHz clocks via SMBus
- Differential outputs can be disabled via pins or SMBus
