5PB1104PGGK8 Electronic Components

5PB1104PGGK8 Electronic Components belongs to 1.8V to 3.3V High-Performance LVCMOS Clock Buffer Family.The 5PB1104PGGK8 is a high-performance LVCMOS clock buffer family of devices. It has an additive phase jitter of 50fs RMS.

There are five different fan-out variations available: 1:2 to 1:10. The 5PB1104PGGK8 supports a synchronous glitch-free output enable (OE) function to eliminate any potential intermediate incorrect output clock cycles when enabling or disabling outputs. It can operate from a 1.8V to 3.3V supply.

Typical Applications

Industrial applications
Automotive:  Radar, Lidar, and other applications

Product Features

-High-performance 1:2, 1:4, 1:6, 1:8, 1:10 LVCMOS clock buffer
-Very low pin-to-pin skew: < 50ps
-Very low additive jitter: < 50fs
-Supply voltage: 1.8V to 3.3V
-3.3V tolerant input clock
-f MAX = 200MHz
-Integrated serial termination for 50Ω channel
-Packaged in 8-, 14-, 16-, 20-pin TSSOP and as small as 2 × 2 mm DFN and 3 × 3 mm VFQFPN packages
-Industrial (-40°C to +85°C) and extended (-40°C to +105°C) temperature ranges
-5PB1104 available in AEC-Q100 qualified, Automotive Grade 1 (-40°C to +125°C)
-5PB1110 available in AEC-Q100 qualified, Automotive Grade 2 (-40°C to +105°C)
