R5F1026AASP Electronic Components

R5F1026AASP Electronic Components belongs to 16 bit microcontroller.R5F1026AASP MCU:True low-power platform (63 μA/MHz) for the general-purpose applications, with 1.8-V to 5.5-V operation, 2- to 16-Kbyte code flash memory, and 31 DMIPS at 24 MHz.

Product Features

①Ultra-low power consumption technology
-HALT mode
-STOP mode
-SNOOZE mode

②RL78 CPU core
-CISC architecture with 3-stage pipeline
-General-purpose registers: (8-bit register x 8) x 4 banks
-On-chip RAM: 256 B to 2 KB
-Address space: 1 MB

③ Code flash memory
-Code flash memory: 2 to 16 KB
-Block size: 1 KB
-Prohibition of block erase and rewriting (security function)
-On-chip debug function

④Operating ambient temperature
TA = -40 to +85 °C (A: Consumer applications, D: Industrial applications)

⑤Power management and reset function
-On-chip power-on-reset (POR) circuit
-On-chip voltage detector (LVD) (Select interrupt and reset from 12 levels)

⑥ Multiplier and divider/multiply-accumulator
-16 bits x 16 bits = 32 bits (Unsigned or signed)
-32 bits x 32 bits = 32 bits (Unsigned)
-16 bits x 16 bits + 32 bits = 32 bits (Unsigned or signed)
