FS32K144HFT0VLLT NXP Electronic Components

The junction to ambient thermal resistance is an industry standard value that provides a quick and easy estimation of thermal performance. Unfortunately, there are two values in common usage: the value determined on a single layer board and the value obtained on a board with two planes. For packages such as the PBGA, these values can be different by a factor of two. Which value is closer to the application depends on the power dissipated by other components on the board.、

Functional operating conditions appear in the DC electrical characteristics. Absolute maximum ratings are stress ratings only, and functional operation at the maximum values is not guaranteed. See footnotes in the following table for specific conditions.

Stress beyond the listed maximum values may affect device reliability or cause permanent damage to the device.All the limits defined in the datasheet specification must be honored together and any violation to any one or more will not guarantee desired operation.Unless otherwise specified, all maximum and minimum values in the datasheet are across process, voltage, and temperature.

FS32K144HFT0VLLT NXP Electronic Components Features

Operating characteristics

– Voltage range: 2.7 V to 5.5 V

– Ambient temperature range: -40 °C to 105 °C for HSRUN mode, -40 °C to 150 °C for RUN mode

Arm™ Cortex-M4F/M0+ core, 32-bit CPU

– Supports up to 112 MHz frequency (HSRUN mode) with 1.25 Dhrystone MIPS per MHz

– Arm Core based on the Armv7 Architecture and Thumb®-2 ISA

– Integrated Digital Signal Processor (DSP)

– Configurable Nested Vectored Interrupt Controller (NVIC)

– Single Precision Floating Point Unit (FPU)

Clock interfaces

– 4 - 40 MHz fast external oscillator (SOSC) with up to 50 MHz DC external square input clock in external clock mode

– 48 MHz Fast Internal RC oscillator (FIRC)

– 8 MHz Slow Internal RC oscillator (SIRC)

– 128 kHz Low Power Oscillator (LPO)

– Up to 112 MHz (HSRUN) System Phased Lock Loop (SPLL)

– Up to 20 MHz TCLK and 25 MHz SWD_CLK

– 32 kHz Real Time Counter external clock (RTC_CLKIN)
