FS32K146HFT0MLQT NXP Electronic Components

FS32K146HFT0MLQT:ARM microcontroller S32K146, M4F, Flash 1M, RAM 128KB.

Device functionality is guaranteed up to the LVR assert level, however electrical performance of 12-bit ADC, CMP with 8-bit DAC, IO electrical characteristics, and communication modules electrical characteristics would be degraded when voltage drops below 2.7 V

Measurements are with maximum output load of 25 pF, input transition of 1 ns and pad configured with fastest slew settings (DSE = 1'b1).

I/O operating voltage ranges from 2.97 V to 3.6 V

While doing the mode transition (RUN -> HSRUN or HSRUN -> RUN ), the interface should be OFF.

Add 50 ohm series termination on board in QuadSPI SCK for Flash A to avoid loop back reflection when using in Internal DQS (PAD Loopback) mode.

QuadSPI trace length should be 3 inches.

FS32K146HFT0MLQT NXP Electronic Components Features

Mixed-signal analog

–Up to two 12-bit Analog-to-Digital Converter (ADC) with up to 32 channel analog inputs per module

–One Analog Comparator (CMP) with internal 8-bit Digital to Analog Converter (DAC)

Operating characteristics

–Voltage range: 2.7 V to 5.5 V

–Ambient temperature range: -40°C to 105°C for HSRUN mode, -40°C to 150°C for RUN mode
