ISL15100IRZ-T7 Electronic Components

ISL15100IRZ-T7 Electronic Components belongs to Single Port, PLC Differential Line Driver.The ISL15100 is a single port differential line driver developed for Power Line Communication (PLC) applications. The device is designed to drive heavy line loads while maintaining the high level of linearity required in OFDM PLC modem links. With 15.5dBm of total transmit signal power into 100 line load, the driver achieves -43dB average MTPR distortion across the output spectrum up to 86MHz.

Product Description

The ISL15100 has two bias current control pins (C0, C1) to allow for four power settings (disable, low, medium, high). In disable mode, the line driver outputs maintain a high impedance in the presence of high receive signal amplitude, so it doesn’t affect TDM receive signal integrity.
The ISL15100 is available in the thermally-enhanced 16 Ld QFN and is specified for operation over the full -40°C to +85°C ambient temperature range.

Product Applications

Power Line Communication differential driver
Pin compatible upgrade to ISL1571IRZ

Product Features

Single differential driver
100MHz Broadband PLC G.hn, EOC, HomePlug AV2
Control pins for enable/disable and supply current selection
High output impedance when disabled for TDM operation
-43dBc average MTPR distortion at full line power
Single +12V or bipolar ±6V nominal supplies
High surge current handling capability
