S912XET256W1MAG Electronic Components Introduction

The S912XET256W1MAG Electronic Components of micro controllers is a further development of the S12XD-Family including new features for enhanced system integrity and greater functionality.The MC9S12XE-Family delivers 32-bit performance with all the advantages and efficiencies of a 16 bit MCU.

The MC9S12XE-Family features an enhanced version of the performance-boosting XGATE co-processor which is programmable in“C”language and runs at twice the bus frequency of the S12X with an instruction set optimized for data movement, logic and bit manipulation instructions and which can service any peripheral module on the device.In addition to the I/O ports available in each module, up to 26 further I/O ports are available with interrupt capability allowing Wake-Up from STOP or WAIT modes.

Product Features

ADC0 Configuration

The ADC module includes four external trigger inputs ETRIG0, ETRIG1, ETRIG2, and ETRIG3. The external trigger allows the user to synchronize ADC conversion to external trigger events. Table 1-17 shows the connection of the external trigger inputs.
