TJA1057GT/3J Electronic Components

Product Introduction

The TJA1057GT/3J Electronic Components is part of the Mantis family of high-speed CAN transceivers.The TJA1057 offers a feature set optimized for 12 V automotive applications, with significant improvements over first- and second-generation CAN transceivers from NXP, such as the TJA1050, and excellent ElectroMagnetic Compatibility (EMC) performance.

A VIO pin on the TJA1057GT(K)/3 variants allows for direct interfacing with 3.3 V and 5 V-supplied microcontrollers.The TJA1057 implements the CAN physical layer as defined in ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5.These features make the TJA1057 an excellent choice for HS-CAN networks that only require basic CAN functionality.

Product Features and benefits

2.1 General

Fully ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 compliantOptimized for use in 12 V automotive systems

AEC-Q100 qualified

2.2 Predictable and fail-safe behavior

Functional behavior predictable under all supply conditionsTransceiver disengages from bus when not powered (zero load)Transmit Data (TXD) dominant time-out function

Internal biasing of TXD and S input pins

2.3 Protection

High ESD handling capability on the bus pins (8 kV IEC and HBM)Bus pins protected against transients in automotive environmentsUndervoltage detection on pins VCC and VIO

Thermally protected

2.4 TJA1057 CAN FD

Timing guaranteed for data rates up to 5 Mbit/s

Improved TXD to RXD propagation delay of 210 ns
